FX40 Optical Light Source (1310/1550) | #FX40-OLS

VeEX | FX40 Optical Light Source (1310/1550) | #FX40-OLS

by VeEX
$195.00 - $195.00
$195.00
$195.00 - $195.00
$195.00

VeEX | PART #FX40-OLS

FX40 Optical Light Source (1310/1550)

DESCRIPTION

Fiberizer® software for Windows® Desktop, Android™, and/or Apple® mobile devices is available to assist in data transfer, record management, and report generation for various VeEX fiber optics testers. View the Fiberizer webpage for more details

INCLUDES

  • FX40 Optical Test Set
  • FX40 Optical Light Source, with Alkaline Battery support
  • Carrying Pouch for V40
  • Quick Reference Guide, FX40, Getting Started Guide, Applicable to FX45/FX48
  • 1-Year Standard Warranty from initial purchase

FEATURES

  • Singlemode and Multimode testing
  • Built-in universal 2.5 mm tip sleeve
  • PON, Telecom, CATV and LAN/WAN applications
  • Dual wavelength laser source and power meter options
  • High accuracy and wide dynamic range
  • Save OPM measurements (>100 single results)
  • Transfer stored results to a PC or upload results to Fiberizer Cloud via micro USB interface for report generation and printing
  • Reference power level setup and recall
  • Splash resistant keypad and chassis design
  • High contrast display - Visible outdoors and backlight for indoor or low light conditions
  • Alkaline or Rechargeable battery option with Auto power off
  • Field interchangeable optical adaptors support multiple connector types and allow easy access for cleaning

FX40 OPTICAL LIGHT SOURCE DATASHEET

    SPECIFICATIONS

    Optical Light Source (OLS) 3

    • Wavelengths: 1310/1490 nm or 1310/1550 nm or 850/1300 nm to OLS wavelengths
    • Test Tone Generation: 270, 1 kHz, 2 kHz
    • Stability: ±0.03 dB for insertion loss measurements

    Visual Fault Locator (VFL) 4

    • Wavelength: 650 nm
    • Connectory style: Universal 2.5 mm
    • Mode: CW or 2 Hz
    • Power Output: 1 mW
    • Laser Safety: Class 2

    General

    • Results saving: 100 without timestamp
    • OPM Remote control data transfer using LT-Sync PC software
    • Communication port: micro USB
    • OLS/OPM adaptor types: FC/SC/ST/LC/E2000, Universal 1.25 mm, Universal 2.5 mm
    • Battery: Alkaline (AA) or Optional NiMH with 5V micro-USB power adaptor
    • Battery operating time: approximately 100 hours (without backlight)

    Notes:
    1. PM1: SM ±5% at -50 to +7 dBm; ±10% -65 to -50 dBm; MM ±8% at -50 to +7, ±13% at -65 to -50 dBm. Applies only with OPM fitted with SC or FC adaptor.
    2. PM2: SM ±5% at -35 to +25 dBm; ±10% -50 to -35 dBm; MM ±8% at -35 to +25 dBm; ±13% -50 to -35 dBm. Applies only with OPM fitted with SC or FC adaptor.
    3. FX40 can support a maximum of two configurations: OLS/VFL or OPM/VFL
    4. Limited to certain configurations
