TEMPO | WIRE STRIPPER 30-20 AWG | #PA1118
TEMPO COMMUNICATIONS | PART #PA1118
WIRE STRIPPER 30-20 AWG
DESCRIPTION
- Head of tool and handles designed at optimum 22º angle to prevent awkward wrist bends
- Spring-loaded open
- Contoured wire stripping areas precision ground for accuracy
- Non-scoring strip and smooth wire cutting
- Features screw cutter and wire loops embedded in frames
- Built-in safety lock
- Gripping jaws on front of tool
- PA1118 will work on Romex household cable
- Not for use on steel or armored wire and cable
- Limited Lifetime Warranty
| Attribute name | Attribute Value |
|---|---|
| Application | Strips 30-20 AWG Wire And Cable |
| Depth | 0.650 IN (17.000 MM) |
| Jaw Type | Gripping |
| Overall Length | 7.100 IN (180.000 MM) |
| Stripping Range | 30 - 20 AWG (0.050 - 0.500 SQ-MM) |
| Type | GripP 20 |
| Weight | 6.500 OZ (185.000 GM) |
| Width | 2.250 IN (57.000 MM) |
| Item Status Date | 04302010 |
| Country of Origin | TW |
| UNSPSC | 43223312 |
| International Harmonize Code | 8203206060 |
| RoHS Indicator | U |
| MSDS Update Flag | N |
Common Questions About the Tempo PA1118 GripP 20 Wire Stripper
What is the Tempo PA1118 Wire Stripper used for?
The Tempo PA1118 GripP 20 is designed for cutting and stripping 30 to 20 AWG wire and cable, making it suitable for electrical, telecommunications, electronics, and other fine-wire applications. Its precision-ground stripping areas help provide accurate, non-scoring wire preparation.
What wire sizes can the Tempo PA1118 strip?
The PA1118 strips 30 to 20 AWG wire, or approximately 0.05 to 0.5 mm². Its contoured stripping areas are precision-ground to help remove insulation cleanly without damaging the underlying conductor.
What features make the Tempo PA1118 comfortable and easy to use?
The PA1118 features an ergonomic 22-degree angled head and handles to help reduce awkward wrist positioning. It also includes a spring-loaded opening, built-in safety lock, front gripping jaws, screw cutter, and wire loops for added versatility.
At a Glance
• Precision wire stripper designed for 30 to 20 AWG wire and cable
• Suitable for electrical, telecommunications, electronics, and fine-wire applications
• Precision-ground stripping areas provide accurate, non-scoring insulation removal
• Ergonomic 22-degree design helps reduce wrist fatigue during repeated use
• Spring-loaded opening, gripping jaws, screw cutter, wire loops, and built-in safety lock
• Compatible with Romex household cable; not designed for steel or armored wire
