TEMPO | Crimpall 22-10 INS.Terms. Clamshell | #PA8021
TEMPO COMMUNICATIONS | PART #PA8021
Crimpall 22-10 INS.Terms. Clamshell
DESCRIPTION
TOOL WITH DIE
| Attribute name | Attribute Value |
|---|---|
| Cable Type | Insulated Terminals And Lugs |
| Connection | Solid Or Stranded Wire, 22-10AWG (0.340 - 6.000 SQ-MM) |
| Crimping Range | 12-10 AWG (Yellow), 16-14 AWG (Blue), 22-18 AWG (Red), (6.000 - 4.000/2.500 - 1.500/0.340- 0.750 SQ-MM) |
| Package | Clamshell Pack |
| Item Status Date | 04302010 |
| Country of Origin | TW |
| UNSPSC | 43223313 |
| International Harmonize Code | 8205595560 |
| RoHS Indicator | U |
| MSDS Update Flag | N |
Common Questions About the Tempo PA8021 CrimpALL Insulated Terminal Crimper
What is the Tempo PA8021 CrimpALL Insulated Terminal Crimper used for?
The Tempo PA8021 is a professional crimping tool designed for terminating insulated electrical terminals and lugs. It provides secure crimp connections for solid and stranded wires, making it suitable for electrical installations, equipment maintenance, and general wiring applications.
What wire sizes and insulated terminals are compatible with the Tempo PA8021?
The PA8021 supports solid and stranded wire from 22 to 10 AWG (0.34 to 6.0 mm²). Its included die features three color-coded crimping ranges: red for 22–18 AWG, blue for 16–14 AWG, and yellow for 12–10 AWG. These crimping cavities accommodate compatible insulated terminals and lugs across different wire sizes.
Does the Tempo PA8021 include a crimping die?
Yes. The PA8021 is supplied as a complete CrimpALL crimping tool with a die set included. The die is configured for insulated electrical terminals and lugs, allowing technicians to handle multiple wire sizes with one tool. The PA8021 is supplied in clamshell packaging.
At a Glance
• Professional CrimpALL crimping tool for insulated electrical terminals and lugs
• Compatible with solid and stranded wire from 22 to 10 AWG (0.34 to 6.0 mm²)
• Red crimping cavity supports 22–18 AWG insulated terminals
• Blue crimping cavity supports 16–14 AWG insulated terminals
• Yellow crimping cavity supports 12–10 AWG insulated terminals
• Complete crimping tool with die included, supplied in clamshell packaging
