JONARD | Mid Span Slit & Ring Tool (1.2mm-3.3mm) | #MS-306
JONARD TOOLS | PART #MS-306
Mid Span Slit & Ring Tool (1.2mm-3.3mm)
DESCRIPTION
The patented MS-306 Mid Span Slit and Ring Tool is designed to provide easy access to optical fibers in outer jackets and buffer tubes. Building on the popularity of the Jonard Tools MS-6 and MS-26 Fiber Optic Mid Span Slitting Tools, we have incorporated a ring feature in the tool to make it even more versatile
Groove Sizes: 1.2-1.5 mm | 1.5-1.8 mm | 1.8-2.1 mm | 2.1-2.5 mm | 2.5-2.9 mm | 2.9-3.3 mm
- Consists of 6 precision slitting grooves and 6 precision ring grooves ranging in size from 1.2 mm to 3.3 mm
- One side of the tool performs radial/ring cuts and the other side slits the cable (longitudinal cut)
- Compact design weighing less than 2.5 oz with included tethering hole makes it perfect to use in tight spaces or on the go
- Indicator line on top of the unit indicates the position of the blade for accurate slitting and ringing
- Replacement blade set available, part number: MS-306RB
Data Sheet - Mid Span Slit & Ring Tools
SPECIFICATIONS
| Cut Type |
Slit, Ring |
|---|---|
| Number of Slitting Grooves |
6 |
| Number of Ringing Grooves |
6 |
| Cable Type |
Outer Jackets, Loose Buffer Tubes |
| Cable Diameter |
1.2 mm-3.3 mm |
| Dimensions | 2.22 in x 1.52 in x 1.63 in (5.64 cm x 3.86 cm x 4.15 cm) |
| Weight | 0.15 lb (67.192 g) |
| UPC # | 811490019829 |
Common Questions About the MS 306 Mid Span Slit and Ring Tool
What is the MS 306 Mid Span Slit and Ring Tool used for?
The MS 306 is used to slit and ring outer jackets and buffer tubes to access optical fibers during mid span fiber installation and maintenance.
Who is this tool designed for?
This tool is designed for fiber technicians and telecommunications crews working with fiber optic cables ranging from 1.2 mm to 3.3 mm in diameter.
What makes the MS 306 suitable for small diameter fiber cables?
The MS 306 features multiple precision grooves that allow controlled slitting and ring cutting on small diameter jackets and buffer tubes without damaging fibers.
At a Glance
• Mid span slit and ring tool for 1.2 mm to 3.3 mm fiber cable jackets and buffer tubes
• Designed for precise access on small diameter fiber cables
• Combines slitting and ring cutting in one lightweight tool
• Compact design ideal for tight spaces and field use
