JONARD | Singlemode Fiber Optic Launch Cable, 1000 m, SC/UPC-LC/UPC | #FLC-1007
JONARD TOOLS | PART #FLC-1007
Singlemode Fiber Optic Launch Cable, 1000 m, SC/UPC-LC/UPC
DESCRIPTION
Designed with unique compact housing and 1000 meters of fiber, this launch cable is perfect for eliminating dead zones in reflectometric tests using an OTDR. This launch cable also features the following.
- Compact housing and shoulder strap make this perfect for on-the-go use
- 6.56 ft (2 m) long pigtails are terminated with an SC/APC connector on one side and an LC/APC connector on the other side for versatility
- Polishing types are color coded for quick and easy identification of the launch cable
- Convenient magnet on bottom of housing allows for quick and easy mounting to fiber racks
- 3281 ft (1000 m) length of fiber is perfect for most OTDR testing applications
Cable Length: 1000 m
Connector Type: SC/APC-LC/APC
DOCUMENTS
FLC-1001 Singlemode Fiber Optic Launch Cable Datasheet
SPECIFICATIONS
| Cable Length |
3280.84 ft (1000 m) |
|---|---|
| Connector Types |
SC/UPC, LC/APC |
| Input/Output Length |
4.9 ft (1.5 m) |
| Max Insertion Loss @ 1310 nm |
≤ 0.35 dB/km |
| Max Insertion Loss @ 1550 nm |
≤ 0.22 dB/km |
| Max Insertion Loss @ 800 nm |
≤ 2.50 dB/km |
| Max Insertion Loss @ 1300 nm |
≤ 0.70 dB/km |
| SM Connector Insertion Loss |
≤ 0.1 dB |
| MM Connector Insertion Loss |
≤ 0.15 dB |
| Return Loss |
≥ 65 dB |
| Weight | 0 lb (0 g) |
| UPC # | 810053352397 |
Common Questions About the Singlemode Fiber Optic Launch Cable
What is the Singlemode Fiber Optic Launch Cable used for?
The Singlemode Fiber Optic Launch Cable is used with an OTDR to eliminate dead zones and allow accurate measurement of long fiber links during reflectometric testing.
Who is this fiber optic launch cable designed for?
This launch cable is designed for fiber optic technicians, telecom installers, and network testing crews performing long distance OTDR testing and fiber analysis.
What makes this 1000 meter launch cable different from shorter launch cables?
This 1000 meter launch cable provides extended fiber length for long haul testing, helping improve event resolution while offering APC and UPC connector options for flexible OTDR setups.
At a Glance
• 1000 meter singlemode launch cable for OTDR testing
• SC to LC connectors for flexible test configurations
• Compact housing with shoulder strap and mounting magnet
• Ideal for long distance and long haul fiber testing
