JONARD | 360° Compression Tool - RG59 and RG6 Connectors | #CTF-180
JONARD TOOLS | PART #CTF-180
360° Compression Tool - RG59 and RG6 Connectors
DESCRIPTION
The Jonard Tools 360° Compression Tool is designed for use on both short and long style F connectors. The tool is ideal for installing CATV network cables. It also features the following.
- 360° of F connector support designed to accommodate PCT connectors
- Compressed length of short and long connectors is 17.9 mm and 20.8 mm respectively, which can be used with most F connectors in conjunction with RG59 and RG6 COAX cables
- Made of durable high carbon steel with a black oxide finish and spring loaded design
- Plastic cushion grips make the tool rugged and provide a comfortable experience
- Integrated handle lock for storage
- Fixed design so no adjustments are needed
Compatible Connectors:
- PCT or other brand short and long style F connectors
Model: F Type for RG59 & RG6 COAX Cables
DOCUMENTS
360° Compression Tool Datasheet
SPECIFICATIONS
| Connector Type |
F Type for RG59 & RG6 COAX Cables |
|---|---|
| Material |
Carbon Steel |
| Dimensions | 5.5 in x 2 in x 1 in (13.97 cm x 5.08 cm x 2.54 cm) |
| Weight | 0.64 lb (290.56 g) |
| UPC # | 811490018464 |
Common Questions About the CTF 180 360° Compression Tool RG59 and RG6 Connectors
What is the CTF 180 360° Compression Tool used for?
The CTF 180 is used to install short and long style F connectors, including PCT connectors, on RG59 and RG6 coaxial cables.
Who is this compression tool designed for?
This tool is ideal for cable installers, telecom technicians, and field professionals working with F connectors on RG59 and RG6 coax cables.
What makes the CTF 180 different from standard compression tools?
The CTF 180 features 360° F connector support, compressed lengths suitable for short and long connectors, durable high carbon steel with black oxide finish, spring-loaded design, ergonomic plastic grips, integrated handle lock, and fixed design requiring no adjustments.
At a Glance
• 360° compression tool for short and long F connectors on RG59 and RG6 cables
• Compressed lengths 17.9 mm (short) and 20.8 mm (long)
• High carbon steel construction with black oxide finish, spring-loaded, ergonomic grips
• Integrated handle lock, fixed design requiring no adjustments
